NVR8-128RT(3U) - 128CH 8MP NVR - 128CH 8MP Real-time NVR,Output: HDMI- 2K/4K &VGA, Audio In/Out, Alarm In/Out, 3 U Case, 16 SATA (8TB), 3200/3840 FPS H.265, 384MB In, 384MB Out- NVR8-128RT(3U) 128CH 8MP NVR
Input: 128 Channel (Via Network) • Output: HDMI(4K) x 2 dual display mode• 3U Case, 16 HDD - Hot Swap • RAID Support • Audio In/Out • Alarm In/Out • 2 x 1000Mbps Network. NVR8-128RT(3U)
Video:
Input: 2 x RJ-45 Network (1000Mbps) Support
Output: HDMI x 2 + VGA, Dual display mode
HDMI1:4K, 1920x1080 (1080P), 1280x1024
HDMI2 / VGA:1920x1080 (1080P), 1280x1024
Bandwidth:
Incoming: 384Mbps
Outgoing: 384Mbps
Decoding Support:
H.265, H.264
Recording:
Resolution: 8MP & lower
Real-Time 128CH 8MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1
FPS: 3200(PAL) / 3840 (NTSC)
Playback:
16 Channels Simultaneously (locally), 9Channels (Remotlly).
Audio: Two way audio
Input: 1 Channel + Depends on Camera inputs
Output: 1 Channel on device (RCA)
Alarm:
Input: 8 Physical Alarm channels + IP Camera inputs
Output: 4 Physical Alarm channels + IP Camera outputs only
Storage:
16 x SATA Hot swap (Up to 8TB Each)
USB Port: total 3
1 x USB3.0, 2 x USB2.0
E-Sata x 1
RAID 0/1/5/6/10 Support with Hot Swap.
Network: 2 x RJ-45
2 x 1000Mbps-
